Product Overview:
Linear Diffuser (Linear Slot Diffuser) – Single Slot (1 Slot)
A high-quality, streamlined diffuser made of pure aluminum, designed for concealed air conditioning systems.
It features a modern, slim design that provides balanced airflow
with an elegant decorative appearance, combining black and white colors
Suitable for villas, hotels, shopping malls, offices, and luxury projects..
Key Features:
· Modern linear design suitable for all types of interior decor.
· High quality, made of pure aluminum with powder coating.
· Even and quiet airflow without noise.
· Adjustable airflow direction with multiple angles via the Deflection Blade.
· Suitable for installation in gypsum ceilings.
· Available in black and white.
· Lightweight.
· Easy to install, remove, clean, and maintain.
· Washable and cleanable.
Technical Details:
|
Item |
Details |
|
Name |
1 Slot Grille Diffuser |
|
Type |
1 Slot Diffuser 1 GRILL DIFFUSER |
|
Shape |
Rectangular as shown in the image |
|
Number of openings |
1 opening |
|
Brand |
LP |
|
Material |
100% Aluminum |
|
Frame |
All grille parts are made of aluminum |
|
Aluminum thickness |
5 mm for the frame and other parts according to international standards |
|
Front measurement |
50 mm |
|
Back measurement |
35 mm |
|
Opening size |
25 mm |
|
Length |
All sizes are available upon request |
|
Color |
White color RAL 9016 Black color RAL 9005 and ability to request a color |
|
Coating type |
High quality powder coating POWDER COATING |
|
Inner blade |
Inner blade available |
|
Air direction control |
Yes, louvered guidance capability |
|
Available Types |
SUPPLY & RETURN |
|
Airflow Rate |
70 to 150 CFM |
|
Noise Level |
Low Noise ≤ 25 dB |
|
Operating Pressure |
0 – 30 Pa |
|
Internal Blade |
Black Blade available in return and supply |
|
Country of Manufacture |
United Arab Emirates |
Product Sizes:
|
Side |
Details |
Measurement MM |
|
|
F |
Face size |
FACE SIZE |
70 |
|
N |
Neck size |
NICK SIZE |
40 |
|
D |
Depth |
DEPTH |
40 |
|
O |
Opening Size |
OPENING |
25 |
|
L |
Length |
LENGTH |
All sizes available (made to order) |
Uses:
· Residential villas
· Hospitality buildings and hotels
· Malls and retail stores
· Theatres and halls
· Offices and administrative headquarters
· Projects HIGH-END INTERIOR DESIGN
Other options:
· A PLENUM BOX addition can be requested.
· A VOLUME CONTROL DAMPER addition can be requested.
· Multiple and different sizes can be requested.
· Special prices are available for large projects.
· Special prices are available for commercial companies and shops.
