Description
SPECIFICATIONS
Brand Name : NoEnName_Null
Certification : None
Choice : Yes
Connection : Female
Head Code : Hexagon
High-concerned chemical : None
Hose Inner Diameter : 32mm
Material : Copper, Brass
Model Number : 1/8"
Origin : Mainland China
Shape : Equal
Technics : Casting
Type : Union
semi_Choice : yes
Fit Tube OD:
3.175mm = 1/8"
4.75mm = 3/16"
6.35mm = 1/4"
7.8mm = 5/16"
9.52mm = 3/8"
12.7mm = 1/2"
15.88mm = 5/8"
Material: Brass
Material:High Quality Brass (CA360 & CA377)
Typical Application:
Instrumentation, hydraulic and pneumatic systems
Pressure:
Pressure: Working Pressure Up To 2000 PSI with a 4:1 safety factor depending on tube size.When using plastic tubing, use the working pressure for type used
Vibration:
Fair resistance-use long nut when greater vibration resistance is needed.
Temperature Range:
-60°F to +250°F(-53°C to +121°C) with metal tubing. When using compatible plastic tubing do not exceed the tubing temperature range.
Package Included: 1 Union!
