Description
Product Overview:
Linear Slot Diffuser – (1 Slot)
A high-quality linear slot diffuser made of pure aluminum, designed for concealed air conditioning systems.
It features a modern, slim design that provides balanced airflow
with an elegant decorative appearance combining white and black colors.
Suitable for villas, hotels, shopping centers, offices, and luxury projects..
Key Features:
· Modern linear design suitable for all types of interior decorations.
· High quality, made of pure aluminum with powder coating.
· Even and quiet airflow distribution without noise.
· Adjustable airflow direction with multiple angles via the Deflection Blade.
· Suitable for installation in gypsum ceilings.
· Available in white and black.
· Lightweight.
· Easy to install, dismantle, clean, and maintain.
· Washable.
Technical Details:
|
Item |
Details |
|
Name |
1 Slot Grill Diffuser |
|
Type |
1 Slot Diffuser 1 GRILL DIFFUSER |
|
Shape |
Rectangular as pictured |
|
Number of slots |
1 slot |
|
Brand |
LP |
|
Material |
100% Aluminum |
|
Structure |
All parts of the grille are made of aluminum |
|
Aluminum Thickness |
5mm for the frame and other parts as per international standard |
|
Length |
Available in all sizes on demand |
|
Color |
White color RAL 9016 Black color RAL 9005 and custom color available |
|
Paint type |
High-quality powder coating POWDER COATING |
|
Inner blade |
Inner blade available |
|
Airflow control |
Yes, blades can be adjusted |
|
Available types |
SUPPLY & RETURN |
|
Airflow rate |
70 to 150 CFM |
|
Noise Level |
Low Noise ≤ 25 dB |
|
Operating Pressure |
0 – 30 Pa |
|
Inner Code |
Black Blade Available in return and supply |
|
Country of Manufacture |
United Arab Emirates |
Technical Table – 1 Slot Linear Diffuser
Basis: 1 Linear Meter (1.0 m)
Material: Aluminum | Application: Supply / Return | Low Noise
📝 Important Technical Notes (Consultant Notes)
· The above values DESIGN DATA are indicative for drawings and tables.
· For precise studies, please request the datasheet for accurate values.
Product Dimensions:
|
Side |
Details |
Measurement MM |
|
|
F |
Face Size |
FACE SIZE |
70 |
|
N |
Neck Size |
NICK SIZE |
40 |
|
D |
العمق |
DEPTH |
40 |
|
O |
قياس الفتحة |
OPENING |
25 |
|
L |
الطول |
LENGTH |
متوفر جميع المقاسات (يصنع حسب الطلب ) |
الاستخدامات :
· Residential villas
· Hospitality buildings and hotels
· Malls and shops
· Theaters and halls
· Offices and administrative headquarters
· Projects HIGH-END INTERIOR DESIGN
Other options:
· A PLENUM BOX can be requested
· A VOLUME CONTROL DAMPER can be requested
· Multiple and different sizes can be requested
· Special prices are available for large projects
· Special prices are available for commercial companies and shops
