Description
Product Overview:
Linear Slot Diffuser (Linear Slot Diffuser) – Single Slot (1 Slot)
A high-quality, sleek linear slot diffuser made of pure aluminum, specifically designed for concealed air conditioning systems.
It features a modern, slim design that provides balanced airflow
with an elegant decorative appearance, combining white and black colors.
Suitable for villas, hotels, shopping malls, offices, and luxury projects.
Key Features:
· Modern linear design suitable for all interior decor styles.
· High quality, made of pure aluminum with powder coating.
· Uniform and quiet air distribution without noise.
· Adjustable airflow angle through the Deflection Blade.
· Suitable for installation in gypsum ceilings.
· Available in white and black.
· Lightweight.
· Easy to install, remove, clean, and maintain.
· Washable and cleanable.
Technical Details:
|
Item |
Details |
|
Name |
1 Slot Grill Diffuser |
|
Type |
1 Slot Diffuser 1 GRILL DIFFUSER |
|
Shape |
Rectangular as shown in the picture |
|
Number of slots |
1 slot |
|
Brand |
LP |
|
Material |
100% Aluminum |
|
Structure |
All parts of the grill are made of aluminum |
|
Aluminum Thickness |
5 mm for the frame and the rest of the parts according to international standards |
|
Front Size |
50 mm |
|
Back Size |
35 mm |
|
Slot Size |
25 mm |
|
Length |
All sizes are available upon request |
|
Color |
White color RAL 9016 black color RAL 9005 and ability to request a color |
|
Type of Paint |
High-quality Powder Coating POWDER COATING |
|
Internal Blade |
Internal blade is available |
|
Airflow Control |
Yes, louvered directionality |
|
Available Types |
SUPPLY & RETURN |
|
Air Flow Rate |
70 to 150 CFM |
|
Noise Level |
Low Noise ≤ 25 dB |
|
Operating Pressure |
0 – 30 Pa |
|
Internal Blade |
Black Blade Available in Return and Supply |
|
Country of Manufacture |
United Arab Emirates |
Product Measurements:
|
Side |
Details |
Measurement MM |
|
|
F |
Face Size |
FACE SIZE |
70 |
|
N |
Neck Size |
NICK SIZE |
40 |
|
D |
العمق |
DEPTH |
40 |
|
O |
قياس الفتحة |
OPENING |
25 |
|
L |
الطول |
LENGTH |
متوفر جميع المقاسات (يصنع حسب الطلب ) |
الاستخدامات :
· الفلل السكنية
· مباني الضيافة والفنادق
· المولات والمحلات التجارية
· المسارح والقاعات
· المكاتب والمقرات الإدارية
· مشاريع HIGH-END INTERIOR DESIGN
خيارات أخرى :
· A PLENUM BOX can be requested.
· A VOLUME CONTROL DAMPER can be requested.
· Multiple and different sizes can be ordered.
· Special prices are available for large projects.
· Special prices are available for commercial companies and shops.
